68 TYPE R Radio Production System System Elements
DEFAULT NETWORK CONFIGURATION - DETAIL
Core - Rear-facing network (“Surface”) interfaces
Core - Front-facing Setup interfaceCore - AoIP device interfaces
IO box - Front-facing Setup interface
* Feature available from a later Software Version
** Subnet Modes are displayed in CIDR notation
Application Management Studio A Studio B* Studio C* AoIP Primary AoIP Secondary
Assist A 172.29.1.1/16 172.17.1.1/16
- - - -
Assist B* 172.29.1.2/16
-
172.18.1.2/16*
- - -
Assist C* 172.29.1.3/16
- -
172.19.1.3/16
- -
Console A
-
172.17.1.11/16
- - - -
Console B*
- -
172.18.1.12/16*
- - -
Console C*
- - -
172.19.1.13/16
- -
Calrec Connect 172.29.1.21/16 172 .17.1. 21/16 172.18.1.21/16* 172.19.1.21/16 192.168.30.100/24 192.168.31.100/24
S/W Updater 172.29.1.22/16 172 .17.1.22/16 172.18.1.22/16* 172.19.1.22/16
- -
Configure 172.29.1.23/16 172 .17.1. 23/16 172.18.1.23/16* 172.19.1.23/16
- -
Router* 172.29.1.24/16
- - - - -
Twin Controller* 172.29.1.25/16
- - - - -
Rear Interface
1 & 2 1 & 2 1 & 2 1 & 2 5 6
Subnets - IP address & Subnet mask**
Application IP address & Subnet mask**
Assist A 172.16.255.25/24
Assist B* 172.16.255.26/24
Assist C* 172.16.255.27/24
Console A 172.16. 255.5/24
Console B* 172 .16.255.6/24
Console C* 172.16.255.7/24
Calrec Connect 172.16.255.60/24
S/W Updater 172.16. 255.40/24
Configure 172.16.255.19/24
Router 172.16.255.10/24
Twin Controller* 172.16.255.11/24
Other
reserved
addresses
172.16.255.1-4/24
172.16. 255.8-9/24
172.16.255.26-28/24
172.16.255.100/24
172.16.255.200/24
172.16.255.253/24
172.16.255.254/24
AoIP port IP address & Subnet mask**
AoIP 1 - Pri 192.168.30.4/24
AoIP 1 - Sec 192.168.31.4/24
AoIP 2 - Pri 192.168.30.64/24
AoIP 2 - Sec 192.168.31.64/24
Application IP address & Subnet mask**
AoIP device UI 172.16.255.100/24
