56 TYPE R Radio Production System Fixing Bracket Assembly Instructions
LARGE SOFT PANEL LINKING (720-999008)
Large Soft panel MU6411 to Large
Soft Panel MU6411 Linking Option:-
FIG 1 LARGE SOFT PANEL TO LARGE SOFT PANEL LINKING
FIG 2 LINKING PANEL PROCEDURE
1st Panel 2nd Panel
2nd Panel1st Panel
End View
Screws
Underside View
Top
