80 TYPE R Radio Production System CORE DSP PACK options
The digital signal processing element of the Type R core allows a combination of different ‘Console Pack’ sizes.
It is designed to be flexible and provide sufficient processing for one, two or three consoles connected to a core.
DSP Pack Sizes
Type R has 4 DSP Packs available:
R20 which supports up to 20 DSP input channels (mono equivalent) - This is the Base DSP pack provided with the Core.
R40 which supports up to 40 DSP input channels(mono equivalent) - This is a customer option.
R80 which supports up to 80 DSP input channels(mono equivalent) - This is a customer option.
R120 which supports up to 120 DSP input channels(mono equivalent) - This is a customer option.
The following table shows the various pack sizes and how the DSP channels , buses and outputs are arranged between 1,2 or 3
consoles.
DSP PACK OPTIONS
DSP PACKAGES TABLE
DSP Packs
R20 Base 20 DSP channel paths
R40 40 DSP channel paths
R80 80 DSP channel paths
R120 120 DSP channel paths
R20 Base 20 DSP channel paths
1 x Console: 20 DSP channel paths, 8 Aux buses, 8 Group buses, 3 Main buses
R40 Option 40 DSP channel paths
1 1 x Console: 40 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
2 2 x Console: 20 DSP channel paths, 8 Aux buses, 8 Group buses, 3 Main buses
R80 Option 80 DSP channel paths
1 1 x Console: 80 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
2 2 x Consoles: 40 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
3 1 x Console: 40 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
2 x Console: 20 DSP channel paths, 8 Aux buses, 8 Group buses, 3 Main buses
R120 Option 120 DSP channel paths
1 1 x Console: 120 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
2 2 x Consoles: 60 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
3 3 x Consoles: 40 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
4 1 x Console: 80 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
1 x Console: 40 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
5 1 x Console: 60 DSP channel paths, 16 Aux buses, 8 Group buses, 3 Main buses
2 x Consoles: 30 DSP channel paths, 8 Aux buses, 8 Group buses, 3 Main buses
