R80 - Option 3
Console 1 Console 2 Console 3
Totals40 CH 20 CH 20 CH
DSP Paths (mono equivalent)
Channel Paths 40 20 20 80
Aux Paths 16 8 8 32
Main & Group Paths 22 14 14 50
Total DSP Paths 78 42 42 162
Mix Paths (mono equivalent)
Main 1/PGM1 Paths
22 14 14 50Main 2/PGM2 Paths
Main 3/REC Paths
Group Paths
Aux Paths 16 8 8 32
PFL Mix Paths 2 2 2 6
AFL Mix Paths 2 2 2 6
Mix Minus Mix Paths 4 4 4 12
Conference Mix Paths 2 2 2 6
Total Mix Paths 48 32 32 112
64 Mix Paths
Mix Paths (mono equivalent) Width Paths Note
Main 1/PGM1 Paths Mono,Stereo or 5.1
30 Pool of 30 Paths, may be assigned as
Mono, Stereo or 5.1
Main 2/PGM2 Paths Mono,Stereo or 5.1
Main 3/REC Paths Mono,Stereo or 5.1
Group Paths Mono,Stereo or 5.1
Aux Paths Mono or Stereo 16 16 Mono or 8 stereo or any combination
PFL Mix Paths Stereo or 5.1 6
AFL Mix Paths Stereo or 5.1 6
Mix Minus Mix Paths Mono or Stereo 4 2 Mono or 2 Stereo or 1 Mono & 1 Stereo
Conference Mix Paths Mono or Stereo 2 1 Mono or 1 Stereo
Total Mix Paths 64
DSP PATH AND MIX PATH SUMMARY TABLE FOR R80 DSP OPTIONS-CONTINUED
