DSP PATH AND MIX PATH SUMMARY TABLE FOR R120 DSP OPTIONS-CONTINUED
R120 - Option 3
Console 1 Console 2 Console 3
Totals40 CH 40 CH 40 CH
DSP Paths (mono equivalent)
Channel Paths 40 40 40 120
Aux Paths 16 16 16 48
Main & Group Paths 22 22 22 66
Total DSP Paths 78 78 78 234
Mix Paths (mono equivalent)
Main 1/PGM1 Paths
22 22 22 66Main 2/PGM2 Paths
Main 3/REC Paths
Group Paths
Aux Paths 16 16 16 48
PFL Mix Paths 2 2 2 6
AFL Mix Paths 2 2 2 6
Mix Minus Mix Paths 4 4 4 12
Conference Mix Paths 2 2 2 6
Total Mix Paths 48 48 48 144
R120 - Option 4
Console 1 Console 2
Totals80 CH 40 CH
DSP Paths (mono equivalent)
Channel Paths 80 40 120
Aux Paths 16 16 32
Main & Group Paths 30 22 52
Total DSP Paths 126 78 204
Mix Paths (mono equivalent)
Main 1/PGM1 Paths
30 22 52Main 2/PGM2 Paths
Main 3/REC Paths
Group Paths
Aux Paths 16 16 32
PFL Mix Paths 6 2 8
AFL Mix Paths 6 2 8
Mix Minus Mix Paths 4 4 8
Conference Mix Paths 2 2 4
Total Mix Paths 64 48 112
R120 - Option 5
Console 1 Console 2 Console 3
Totals60 CH 30 CH 30 CH
DSP Paths (mono equivalent)
Channel Paths 60 30 30 120
Aux Paths 16 8 8 32
Main & Group Paths 30 14 14 58
Total DSP Paths 106 52 52 210
Mix Paths (mono equivalent)
Main 1/PGM1 Paths
30 14 14 58Main 2/PGM2 Paths
Main 3/REC Paths
Group Paths
Aux Paths 16 8 8 32
PFL Mix Paths 6 2 2 10
AFL Mix Paths 6 2 2 10
Mix Minus Mix Paths 4 4 4 12
Conference Mix Paths 2 2 2 6
Total Mix Paths 64 32 32 128
