Chapter 4
4-25
- Remove the waste ink tube joint carefully so that ink does not spout.
- To prevent ink from dripping off, hang the waste ink tube joint on the side plate with the joint up. Take extra care not to damage the ink tube.
F-4-56
Precautions about Reinstallation of Purge Unit
When reinstalling the waste ink tube joint, insert it deeply until it clicks. Also check that the joint is not disconnected and the tube is not buckled.
F-4-57
To Next Page
