Note
• If the Tab Selection screen is not displayed, press the Menu button.
4. Press the OK button.
The Set./Adj. Menu is displayed.
5. Press â–² or â–¼ to select Maintenance, and then press the OK button.
6.
Press â–² or â–¼ to select Replace P.head, and then press the OK button.
Ink is now filled.
After about two minutes, a message is shown on the Display Screen instructing you to open the Top Cover.
Replace the Printhead
1. Open the Top Cover.
Instructions are now shown on the Display Screen regarding Printhead replacement.
Important
• During Printhead replacement, do not move the Carriage from the position indicated. If you acciden-
tally move the Carriage, you will hear a warning tone, and Printhead replacement is no longer possi-
ble.
If you move the Carriage by mistake, close the Top Cover. The Carriage will be moved to the posi-
tion as indicated.
Maintenance and Consumables
>
Printheads
>
Replacing the Printhead
iPF655
11
812
To Next Page
