4- 25
îš‹ Replacing the Printhead
TOP
Chapter 3
Printing Methods for
Different Objectives
Chapter 4
Maintaining the
Printer
Chapter 5
Using the Printer in a
Network Environ-
ment
Chapter 6
Troubleshooting
Chapter 7
Operation of the
Function Menus
Index
Contents
Chapter 2
Using a Variety of
Media
Chapter 1
Basic Procedures
6
Open the upper cover.
Rep. P.head OK is displayed on the printer
operation panel.
Important
z Do not touch any areas other than those indicated.
Your hands could get dirty or this could damage the
printer.
z Before you start the procedure, wring out a damp cloth
and clean the carriage cover, printhead cover, and
printhead lock lever if they are dirty.
7
If the printhead adjustment lever is in either
the high or low position, return it to the center
(normal) position, then raise the carriage
cover completely.
8
Raise the carriage cover so it is completely
open.
To Next Page
