Cardinal 190 User Manual

8400-M022-O1 Rev K  Model 190 Indicator
110
Setup
Enter SETUP and proceed to the Options Setup.
option
With option displayed, press the TARE  key. The display will change to show opt=.
Proceed to the opt= parameter.
opt?
With opt? displayed, press the TARE  key. The display will change to no. Press the
Fn/ key to toggle to yes and press the TARE  key. The display will change to opt=.
Proceed to the opt= parameter.
Otherwise, to skip the Options Setup, press the TARE  key to advance to the fUnC?.
prompt.
oPt= (Option)
Press the TARE  key to show the current setting. If the setting displayed is acceptable,
press the TARE  key again to save it.
Otherwise, use the Fn/▲ key to toggle to a new setting and press the TARE  key to save
it. Allowable values are:
0 = No Option Card Installed
1 = Serial Interface, Ethernet, Wi-Fi, or USB Option Card Installed
2 = not applicable
3 = not applicable
4 = Digital to Analog Converter Option Card Installed
bAUd= (Option Card Baud Rate)
Press the TARE  key to show the current setting. If the setting displayed is 96, press the
TARE  key again to save it.
Otherwise, use the Fn/ key to toggle the baud rate setting to 96 (9600 Baud) and press
the TARE  key to save it.
NOTE: The default baud rate is 9600 and should not be changed.
Prty= (Option Card Parity Setting)
Press the TARE  key to show the current setting. If the setting displayed is 0, press the
TARE  key again to save it.
Otherwise, use the Fn/ key to toggle the parity setting to 0 (No Parity with 8 data bits) and
press the TARE  key to save it.
NOTE: The default parity is 0 (No Parity with 8 data bits) and should not be changed.
