Appendix A. Modes and Events SMARTH
LED
Flashing
Battery State
Mode or Event
Purple
For 2 seconds
Normal or
Low Battery
● Mobile pairing successful
● Mobile connected
● IC pairing successful
Purple
For 2 seconds
Charging
● Mobile pairing successful
● Mobile connected
● Rider B connected
● Intercom pairing successful
● Set VOX to enabled
● Set VOX to disabled
Purple
Fast (3 times)
Charging
● Power on
Purple
Fast (repeating fast)
Normal or
Low Battery
● Click-to-Link
Yellow
For 2 seconds
Normal or
Low Battery
● Rider C connected
● DMC intercom pairing successful
Yellow
Fast (repeating)
Normal,
Low Battery,
or Charging
● Incoming/outgoing Click-to-Link
Orange
Fast (repeating fast)
Normal,
Low Battery,
or
Charging
● DMC intercom Grouping
Orange
Fast (repeating slow)
Normal or
Charging
● DMC intercom Active mobile call,
voice via mobile
● DMC intercom Standby
Orange
Slow twice (repeating slow, every 3
seconds)
Normal or
Charging
● DMC intercom Incoming/outgoing
call (intercom or mobile)
● DMC intercom Audio active
(intercom, FM, A2DP, GPS,
Feature/Settings menu)
Purple/Red
Fast purple and then red for 3 seconds
(repeating)
Charging
● Active mobile call, voice via mobile
● Standby
Purple/Red
Slow purple, fast red, slow purple, and
then red for 3 seconds (repeating)
Charging
● Incoming/outgoing call (intercom or
mobile)
● Audio active (intercom, FM, A2DP,
GPS, Feature/Settings menu)
Purple/Red
Alternating slow (5 times)
Charging
● Reset pairing
Purple/Red
Alternating slow (repeating)
Normal,
Low Battery,
or
Charging
● Pairing GPS
Purple/Red
Alternating fast (repeating)
Charging
● Pairing intercom rider B
Blue/Red
Alternating fast (repeating)
Normal,
Low Battery,
or
Charging
● Pairing Mobile
