CS 3500 User and Installation Guide (9H4853)_Ed07 31
3 Press the power button for one second to power on the CS 3500.
4 Let the CS 3500 warm up for approximately three minutes to enable the antifog feature on the tip.
Using the Collar to Scan Anterior Teeth
It is recommended that you use the collar when scanning the anterior teeth. Slide the collar onto the
CS 3500 tip as illustrated.
Scan the anterior teeth, and remove the collar to scan the remaining teeth.
Always disinfect the body of the CS 3500, and clean and sterilize the tip and collar after each
use.
Important: The removable scanner tip and collar are autoclavable up
to 20 cycles. After 20 cycles, discard the tip and collar. See the CS
3500 Safety, Regulatory, and Technical Specifications User Guide for
more information.
