CS 3500 User and Installation Guide (9H4853)_Ed07 47
3 Select the corresponding tooth on the tooth number selection arch diagram.
4 Left-click and drag to draw the margin line around the preparation.
5 Examine the margin line on the 3D model and do any of the following:
• To edit the margin line, click on the margin line to select it. Click . Redraw the section of
the margin line you want to alter, and be sure it connects with the existing margin line.
• To delete the margin line, click on the margin line to select it. Click .
6 To view margin line references outside of the CS 3500 Acquisition interface, use the CS Mesh
Viewer that was installed on your desktop.
