62-61753-21
7-27
Alarm
NO.
Steps
ALARM / CAUSE
CORRECTIVE ACTION
37 CHECK LOW SPEED RPM
ï‚· TRIGGER-ON:
"Check Engine Sensor" alarm not active (if so, refer to alarm 130 first) and:
the microprocessor is calling for low speed and speed being read is less than 1300 or greater than
1550 for more than 60 seconds (120 seconds when the microprocessor calls for a change from high
speed to low speed, or when the unit first starts)
ï‚· UNIT CONTROL: Engine operation: Shutdown and alarm.
Standby operation: Will not activate in standby.
ï‚· RESET CONDITION: Auto Reset if the engine speed is within 1320 to 1530 for 60 seconds or alarm
may be manually reset via keypad or by turning the unit off, then back on again.
NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, the active
alarm should clear itself (refer to reset condition above). Operate the unit through the appropriate modes to see if
any active alarm occurs. Continue with the steps below as necessary.
1
Check Model Number
a. Verify that the model number on
the Unit Data label matches the
model number shown in the micro-
processor Unit Data list.
Configure the unit for the correct model number. (Refer
to Section 5.1.1.)
2
Force Low Speed operation
a. Using Functional Parameters, set
the Low Speed Start Up Delay to
10 minutes and start unit.
Unit will run in low speed. Speed must be within range
provided above. Adjust speed linkage as needed. Re-
fer to Section 8.4.9
b. Check LED27
LED27 must be OFF.
3
Check Engine Speed
a. Check actual engine speed using
hand held tachometer.
Refer to Section 2.8 for required speed. Adjust engine
linkage setting as needed. Refer to Section 8.4.9
b. Compare actual speed with those
shown on display.
Both readings within ± 50 RPM.
4
Check Engine Air-Intake System
a. Check air filter.
Replace if required.
b. Inspect air intake system.
Hoses & tubes in good condition.
No kinks or restrictions.
5
Check Engine Fuel System
a. Check fuel tank level.
Must have enough fuel to run engine.
b. Check fuel lines.
Connections are tight and not leaking.
No kinks or sharp bends in the lines.
c. Check fuel screen.
Fuel screen is located in the inlet fitting to the lift pump.
Screen must be clean.
d. Check fuel filters.
Fuel filters must be clean and allow full flow of fuel
through them.
6
Check Engine Exhaust System
a. Inspect the exhaust system.
Must be clear and unobstructed.
