Carrier VECTOR 1550 Series - Page 81

62-61753-21
3-33
c. Lock / Unlock the Remote Control Panel
LOCKING THE PANEL:
Press and hold the Carrier Logo for
approximately one second and then
release.
The lock indicator light will illuminate.
CARRIER
LOGO
LOCK INDICATOR LIGHT
UNLOCKING THE PANEL:
Press the Carrier Logo for 10 seconds
The lock indicator light will de--energize.
d. Preset Set Point With Remote Control Panel
The control panel allows the user to pre-set 5 different temperatures.
NOTE
Once preset set points have been chosen, only those 5 designated set points can be used.
1. Place SROS in the “START /RUN” position.
2. Press Carrier logo and the lock light will illuminate.
3. Press UP ARROW for 10 seconds.
P1 will be displayed.
4. Set lowest set point required.
5. Press Carrier logo and P2 will be
displayed. Set next highest tem-
perature required.
6. Follow same procedure for the next
three temperatures.
