14.3 Communication Settings
14.3.1 What are communication settings?
These settings are menu item selections for determining communication specifications when
connecting to devices such as an electronic printer or a computer.
The settings here are effective for both RS-232C and DATA I/O communication specifications.
When a printer or another device is connected to the DATA I/O connector, set the balance
communication settings to “Standard Setting 1”.
Five standard settings are stored in the balance, that are composed for frequently used types of
communication. Selecting a standard setting allows all of these items to be set at once:
communication speed (baud rate), delimiters, parity (and bit length), stop bit, data format,
and handshake. Setting combinations that are not included in the standard settings may be
selected by individual items in the User Settings.
14.3.2 Standard Setting
The combinations shown in the table below are available as standard setting 1 to standard
setting 6. In the communication settings menu, the standard settings 5 and 6 cannot be
selected. The standard settings 5 and 6 (WindowsDirect) can be set easily without entering the
menu (see 6.2.1).
Display at
menu item
selection
Compatible
manufacturer
Baud
rate
Delimiter
Parity
(and bit
length)
Stop bit
Data
format
Hand
shake
Standard
setting 1
iF:F1
CAS
(standard)
1200 C/R None (8) 1 dF1
Hard
ware
Standard
setting 2
iF:F2 (extended) 1200 C/R None (8) 1 dF2
Hard
ware
Standard
setting 3
iF:F3 Mettler 2400 C/R+L/F Even (7) 1 dF3
Hard
ware
Standard
setting 4
iF:F4 Sartorius 1200 C/R+L/F Odd (7) 1 dF4
Hard
ware
Standard
setting5
SEtwin |
CAS
Windows
Direct
300 Win | None (8) 1 dF1
Hard
ware
Standard
setting6
SEtwin -
CAS
Windows
Direct
300 Win - None (8) 1 dF1
Hard
ware
User
settings
(see 14.3.3)
iF:USEr
User
set
User set User set User set
User
set
User
set
* Refer to 6.2.1 for selection of these standard settings.
