31
x When data is outputted to the computer by WindowsDirect function, the
effect is the same as “typing the numerical value displayed on the balance
and pressing Enter key on the computer’s keyboard”.
If you wish the effect of “pressing → key” instead of
“pressing Enter key”on the computer’s keyboard”, select “SEtwin -” in the
above step 1, instead of “SEtwin |”.
The “SEtwin -” setting menu display appears when the [MENU] key is
pressed one more time from “SEtwin |”.
x The communication parameters selected by “SEtwin -” or “SEtwin |” settings
here are listed in the table in 14.3.2.
x After WindowsDirect setting has been made using the “SEtwin -” or
“SEtwin |” setting, individual communication parameters can be changed
using the Communications Settings menu (14.3). In this case, the ¨
(stability mark) may still appear if you go to the “SEtwin -” or “SEtwin |”
display but WindowsDirect may not operate. To restore WindowsDirect
optimal settings then, first remove the stability mark by pressing the [O/T]
key at the “SEtwin -” or “SEtwin |” display. This restores the default
Communications settings. Then, reset “SEtwin -” or “SEtwin |” following the
procedure described in 6.2.1.
6.2.2 Connecting the RS-232C Cable
1 Check that the balance is in “oFF” or
“STANDBY” status.
2 Remove power from the balance and turn off
the computer.
3 Connect the RS-232C cable to the RS-232C
connector on the back of the balance.
4 Connect the RS-232C cable to the computer.
RS-232C connector
(When not set) (When set)
To Next Page
