7.3 Menu Item Selection Procedures
See the menu map (Appendix A-1).
The CAUW-D/CAUW/CAUX/CAUY series menu consists of four levels with the most
often used menus in the first level for an easy-to-use structure. The menu can be entered by
pressing the [CAL] key from the mass display. The menu operation keys for movement in the
menu tree are shown in the following table. From any menu level, pressing repeatedly or
holding down the [POWER] key returns to the mass display.
During Menu selection
Operated
key
Pressed once and released
Pressed and held for
about 3 seconds
Moving
direction
on Menu Map
[POWER]
Return to the menu above the current
menu level.
Returns to mass display.
←
[CAL] Moves to the next menu item.
↓
[O/T]
Select the displayed menu item, or move to the next menu
below the current menu level.
→
[UNIT
In numerical value input, increases the numeric value of the
blinking digit by 1.
[PRINT] In numerical value input, moves the blinking digit to the right.
[1d/10d] No effect.
1 Press the [CAL] key from the mass display.
“i-CAL” appears.
(The type of regular-use calibration appears.
“i-CAL” is default of CAUW-D/CAUW/
CAUX series. In the CAUY series this is
“E-CAL” or “E-tESt”.)
2 After that, pressing the [CAL] key changes the
display in the order shown below.
