1-GENERALINFORMATION

Operator'smanualstorageonthemachine

Alwayskeepthemanualinthelocationprovidedforthat

purpose(behindtheoperator’sseat).Makesureitisal-

wayscompleteandingoodcondition.Ifyouwishtoob-

tainextracopies,orcopiesinlanguagesotherthanthatof

thecountryofuse,consultyourCASECONSTRUCTION

Dealer.

YLNR3P-0021

1-6
