CASE CONSTRUCTION CX160C - Auxiliary Hydraulic Circuits

4-OPERATINGINSTRUCTIONS
Auxiliaryhydrauliccircuits
Yourmachinehastwotypesofauxiliaryhydrauliccircuits.Onecircuitisforsingleowequipment,suchashydraulic
breakers.Thesecondtypeofcircuitisdesignedfordualowusesuchasdemolitiongrabs,etc.
ConsultyourCASECONSTRUCTIONDealertoselecttheoptionalaccessorycompatiblewithyourmachineandto
correctlyadjusttheowrequiredforitsuse.
NOTICE:Topreventfailureordamagetothetool,make
surethatyouselectthecorrectcircuitcongurationand
owrateforthetool.
Hydraulicbreakerorsingleowhydrauliccircuitconguration
Pedaltype/standardright-handlever
1.Makethenecessarytoolconnectionsandthen,using
ahexagonalwrench,openthesupplyvalveslocated
atthetipofthearm,left-handandright-handside.
VOHLGR-0161
2.Switch(1)locatedonthefrontright-handconsole,cor-
respondingtothehydraulicbreaker.
Everytimetheswitch(1)ispressed,oneofthediffer-
enttypesofowpatternsrecordedforthepumpcan
beselected.Forowsettingmethod,refertopage
3-26.
VOHLGR-0022
3.Theiconoftheaccessoryassociatedwitheachtype
ofowdisplaysonthescreen.
010FD87FZ3
4-27
