3-CONTROLSANDINSTRUMENTS

Positionoftheoperator’scompartmentcontrolsandaccessories

WARNING

Misusehazard!

Beforestartingtheengine,makesureyouarefullyawareofthelocationandthefunctionofeach

control.

Failuretocomplycouldresultindeathorseriousinjury.

W0226A

SMIL15CEX1246GB1

3-3
