Accesstooperator'splatform
Frame-Access/Exit
Cabdoor
CAUTION
Pinchhazard!
Becarefulnottogetyourhand,clothes,etc.caughtinthedoorwhenclosingit.
Failuretocomplycouldresultinminorormoderateinjury.
C0046A
Toopenthedoor,usethehandle(1)fromtheoutsideand
usethehandle(2)fromtheinside.
SMIL15CEXX527AB1
YARHC2-0022
Thedoorcanbelatchedincompletelyopenposition.To
unlatchthedoor,tiltthelever(3)downward.
NOTICE:Donotleavethedoorajar.Fixitinalatched
position.
NOTICE:Whenseatedintheoperator’scompartment,
withtheenginerunning,makesurethatyoudonotoper-
atetheleft-handcontrolleverinadvertentlywhenunlock-
ingthedoor.Topreventanyincident,placethefunction
cancellationleverinthecenterposition.(Refertopage
3-51).
YARHC2-0033
