CASE CONSTRUCTION CX160C - Front Right-Hand Console

3-CONTROLSANDINSTRUMENTS
Frontright-handconsole
1.TEMPERATUREPROBE
Donotplaceobjectsontopofit.
NOTE:Toensurecorrectfunctioningandfulleffective-
nessoftheairconditioningsystem,itmustberunat
leastonceaweek,evenifonlyforashorttime.
2.MONITORDISPLAY
Clock,FuelMeter,CoolantWaterThermometer,Hy-
draulicOilThermometer.
Displaysthefunctionselectionstatus.
Displaysthemachinestatus.
Displaysthebackmonitor.
Displaysthemachinemaintenancestatus.
3.MONITORSWITCH
Selectsthemachinestatus.Themonitordisplaycan
beswitched.
4.AIRVENTS
Theairventscontrolthecirculationanddirectionofair
ow.Theairventsareopenedandcontrolledmanu-
ally.
ATTENTION:Theairventsmustalwaysbeopen
whentheairconditioningisinuse.
6L2VLK-0021
1.Temperatureprobe
2.Monitordisplay
3.Monitorswitch
4.Airvent
3-17
