3-CONTROLSANDINSTRUMENTS
Functioncancellationleverandsafetybar
WARNING
Unexpectedmachinemovement!
Beforeleavingtheoperator'scompartment,
thefunctioncancellationlevermustbeinthe
centralpositionandthesafetybarmustbein
theinwardposition.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0223A
Thesafetybar(1)isdesignedtopreventtheoperatorfrom
leavingtheoperator’scompartmentwithoutrsthaving
retractedthesafetybarintotheleft-handcontrolarm.
Thelever(2)operatesthesafetybar(1)andcancelsthe
functioningofthecontrolleversandpedals.Whenthe
lever(2)isincentralposition,thesafetybar(1)isininward
positioninthecontrolarmandtheattachment,traveland
swingfunctionscannotbeoperated.
NOTE:Theenginemustbestartedwiththesafetybar
retracted.Ifthesafetybarisextended,itisnotpossible
tostarttheengine.
NZIMV6-0011
Tomaketheattachment,travelandswingfunctionsoper-
ationaloncemore,pushthelever(2)forwardforthesafety
bar(1)tocomeoutofthecontrolarm.
NOTE:Itisalsopossibletocancelallcontrolsbycom-
pletelyraisingtheleft-handcontrolarm.Pullthelever(2)
backward.
NZIMV6-0022
