CASE CONSTRUCTION CX160C - Fan and Alternator Drive Belt

6-MAINTENANCE
Fanandalternatordrivebelt
Servicespecications
Visualcheck:Every10hoursoreveryday
Checkbelttension:Every250hours
Checkingthetension
NOTICE:Iftheenginerunswiththebeltslack,thebelt
canslipinitshousingandcausetheenginetooverheat
orthebatterytoreceiveinsufcientcharge.
SMIL15CEXX782AA1
Withengineshutdownandthestarterswitchkeyre-
moved,useyourngertoexertapressureofabout10kg
(22.0lb)atthecentreofthebelt.
Thetensionslackshouldbebetweenabout6mm(0.2in)
and8mm(0.3in).
NOTE:Checkifthereareanysignsofweardamageto
thepulleysorthebelt.
Checkcarefullytoensurethatthebeltiscorrectlyposi-
tionedinthepulleygrooves.
Ifthebeltisstretched,crackedorfrayed,itmustbere-
placed.
CS98M560TBP12
Tensionadjustment
Removetheretainingscrews(1)and(2).Usetheadjust-
mentscrews(3)tomovethealternatoroutwardsuntilbelt
tensioniscorrect.Tightenthealternatormountingbolts
(1)and(2).
SMIL15CEXX783AB3
6-58
