CASE CONSTRUCTION CX160C - Swing Reduction Gear

6-MAINTENANCE
Swingreductiongear
SERVICESPECIFICATIONS
OILLEVELCHECK:Every250hours
OILCHANGE:Every1000hours(aftertherst250hoursduringtherun-inperiod)
OILCAPACITY:5L(1.321USgal)
TYPEOFOILANDGREASE:(Refertopage6-4)
WARNING
Hotsurfacepossible!
Waitforallcomponentstocoolbeforeper-
forminganyoperation.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0251A
LEVEL
1.Parkthemachineonat,horizontalground.Stopthe
engineandremovetheignitionkey.
2.Removethedipstick(2).Theoilshouldcomeupto
thehatchedarea.Ifnecessary,addmoreoilthrough
thellerhole(1).
3.Installthedipstick(2).
SMIL15CEXX762AA1
DRAININGANDREFILLING
1.Parkthemachineonat,horizontalground.Stopthe
engineandremovetheignitionkey.
2.Removethedipstick(2)andthellerplug(1).
SMIL15CEXX762AA2
6-48
