6-MAINTENANCE

Fuses

NOTE:Beforechangingfusesorrelays,turnthestarter

switchkeytothe"Shutdown"position.

NOTE:Neverreplaceafusewithafuseofadifferentam-

perage.

Toaccessthefusebox,openthecoverlocatedbehindthe

operator'sseat.

1D2MQ9-002A1

Toaccessthefuses,removethecoveronthebox.A

noticeonthecovergivesthefunctionandamperageof

eachfuse.

NOTE:Toremoveorinstallafuse,usethenotchinthe

upperright-handcornerofthecover.

1D2MQ9-003A2
