CASE CONSTRUCTION CX160C - Windshield

3-CONTROLSANDINSTRUMENTS
Windshield
CAUTION
Pinchhazard!
Makesureyoucorrectlyfollowtheinstructionsinthismanualwhenhandlingthewindshield.Ifyou
donothandlethewindshieldcorrectly,itcouldslipandinjureyourngersorhands.
Failuretocomplycouldresultinminorormoderateinjury.
C0045A
WARNING
Lockthegatewiththegatelocklever.
Opening
1.Foldthesunshield(1)backagainstthewindshieldand
operatethelever(2).Holdthelowerandupperhan-
dles(3)andcarefullyraisethewindshield.
DU3Y32-0011
2.Pullthewindshieldtotherearuntilitengagesperfectly
behindthecab.
DU3Y32-0022
Closing
1.Usethelever(2)toreleasethewindshield.
2.Holdbothhandles(3)andcarefullylowerthewind-
shield.Makesurethewindowiscompletelydown.
3.Makesurethetopofthewindshieldiscorrectly
latched.
GSVC6J-0013
