CASE CONSTRUCTION CX160C - Quick Coupler (optional)

4-OPERATINGINSTRUCTIONS
Quickcoupler(optional)
WARNING
Crushinghazard!
Neverputyourhandsinsidethequickcouplerwhentheengineisrunning.Turnofftheengineand
waitforallmovementtostop.
Failuretocomplycouldresultindeathorseriousinjury.
W0252A
Installthequickcoupleronthearmandontheconnecting
rodusingtheCASECONSTRUCTIONlinkagepins(1)
suppliedandthenmakethesupplylineconnections.
NOTICE:Thequickcouplercanbeusedinconjunction
withhydraulicbreakers,butisnotdesignedtowithstand
excessivevibrationoverlongperiodsofthetime.Itis
thereforerecommendedtoremovethequickcoupler,to
reducetheriskofprematurewear,failuresorbreakage.
Ifyoudodecidetouseahydraulicbreaker,alwaysorien-
tatethebreakertowardsthemachineandneveruseitas
alever,asthestresswouldbebornebythequickcoupler
cylinder.
XOQMIB-001A1
Quicktoolinstallationandremoval
NOTICE:ThisquickcouplerisdesignedtobeusedwithCASECONSTRUCTIONbuckets.
Thisbeingsaid,otherbucketsmaybeused,providedthediameterofthepinsandthewidthbetweenthebucketlugs
aremodiedtomeetthedimensionsneededtotthequickcoupler(pins,washers,bushings,etc.).
ConsultyourCASECONSTRUCTIONDealer.
WARNING
Hazardtobystanders!
ALWAYSmakesuretheworkareaisclearofbystandersanddomesticanimalsbeforestartingthis
procedure.Knowthefullareaofmovementofthemachine.Donotpermitanyonetoenterthearea
ofmovementduringthisprocedure.
Failuretocomplycouldresultindeathorseriousinjury.
W0245A
Installation
1.Makesurethetooltobeinstalledislayingsafelyon
at,levelgroundandthatitisttedwiththepinssup-
pliedwiththequickcoupler.
2.Placetheswitch(1)inunlockingposition.Theaudible
alarmdevicewillsound.(Refertopage“3-53”)
SMIL15CEX0960AB2
4-22
