Movingtheunit
Machinetravel
WARNING
Controlscanbereversed!
Inthenormaltravelposition,theoperator's
compartmentisabovetheidlerwheelsandthe
travelreductiongearsaretotherearoftheup-
perstructure.Iftheupperstructureisturned
180degreesinrelationtotheundercarriage,
thecontrolsarereversed.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0289A
NOTICE:Beforeundertakinganytravel,raisetheattach-
ment.
NOTE:Travelspeeddependsonthetiltingangleofthe
travelcontrolleversandpedalsandthespeedtravel
modeselected.
NOTE:Thedifferenttravelcongurationsdescribedhere-
afterarewiththetravelreductiongearstotherearofthe
upperstructure.
SMIL15CEXX697AA1
TRAVELALARM
Thetravelalarmsoundscontinuouslyorfor10seconds,
dependingthepositionoftheswitch.(Refertopage3-54).
STRAIGHTLINETRAVEL(forwardtravel)
Pressthetwopedals(orpushthetwolevers)forwardsat
thesametime.
