CASE CONSTRUCTION CX160C - Rear View Mirrors

3-CONTROLSANDINSTRUMENTS
Rearviewmirrors
Installingpositionoftherearviewmirror
SMIL15CEXX677EB1
Mirroradjustment
WARNING:
Beforeoperation,adjusttherearviewmirrortoensurevisibility.
Incorrectadjustmentgivesyouinadequatevisibilitythatmaycauseaseriousphysicalinjury.
showstherangereectedineachmirror.
SMIL15CEXX683EB2
MirrorA(Cabupper)
Adjustthemirrortoseetheleftrearedgeofthemachine
bysight.
Tighteningtorqueofbolt(1):71.6-91.2N·m(52.8-
67.3lbft)
•
Installthemirrorinthepositionintherightillustration.
L:155mm(6.1in)
286C61C03
3-63
