CASE CONSTRUCTION CX160C - Quick Coupler (optional)

6-MAINTENANCE
QUICKCOUPLER(optional)
Servicinginstructions
EVERYDAYANDBEFOREEACHINSTALLATIONOF
THEQUICKCOUPLER:
•
Checkthatthelockingbarfunctionscorrectlyandthat
itisnotfouledbyforeignmatter.
•
Checkthequickcouplercylinderhosesforfreemove-
ment.
•
Checkthereturnspringanditsmountinghardware.
•
Checkforanysignsofcracks.
WARNING
Improperoperationorserviceofthismachine
canresultinanaccident.
Ifyoudonotunderstandamaintenanceproce-
dure,ordoubtyourabilitytoperformamain-
tenanceprocedurecorrectly,seeyourautho-
rizeddealer.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0157A
Modicationofthequickcouplerwithoutpriorauthoriza-
tioncancauseseriousinjury.Donotcarryoutanymod-
icationwithoutauthorization.ConsultyourCASECON-
STRUCTIONDealer.
NOTICE:Ifyouuseyourquickcouplerunderparticularly
severeconditions(withahydraulicbreakerorinacorro-
siveenvironment,etc.)theservicingandinspectioninter-
valsmustbereduced.
CT02C242TBP12
Incorrectfunctioning
NOTE:Makesurethattheattachmentisinfullcontact
withthegroundbeforecarryingoutthefollowingchecks.
Ifthequickcouplerdoesnotworkcorrectly,checkthe
followingitems:
•
Thatnopinisbroken,bentorlost.
•
Thatnoforeignmatterisfoulingthesafetydevice.
•
Theconditionofthereturnspring.
•
Thatthecylinderisnotdamagedorbent.
•
Thattherearenoleaksfromhydraulichoses,etc.
Iftheproblempersistsafterallthesechecks,consultyour
CASECONSTRUCTIONDealer.
6-3
