6-MAINTENANCE

Attachment

Monoblocboom/arm

SMIL15CEXX713FB4

NOTE:Ifthefollowinglinkagepointsarenotequippedwithoriginalparts,thesepointsmustbelubricatedevery50

hours.

Every1000hours

Boombottompin:(2)

Boomcylindertoppin:(2)

Armcylinderbottompin:(1)

SMIL15CEXX714AB5

6-13
