6-MAINTENANCE

4.Removethefourscrewsandtilttheheadlight.

PV5ETN-004A8

5.Pulltheclipoutward,removethebulbandinstallabulb

ofthesamewattage(70W).

NOTE:Neverputyourngersonatungsteniodidebulb.

6.Installtheclip,puttheheadlampbackinpositionand

installthescrewsandtheplug.

7.Installtheswitchbracket.

PV5ETN-005A9

6-92
