CASE CONSTRUCTION CX160C - Arms; Bucket and Arm Types; Quick Coupler (Optional)

8-SPECIFICATIONS
Arms
2.23m(87.80in)2.62m(103.15in)3.05m(120.08in)
(A)(Maximumdiggingreach)8.67m(341.34in)9.04m(355.91in)9.38m(369.29in)
(B)(Maximumdiggingreachat
groundlevel)
8.5m(334.65in)8.87m(349.21in)9.22m(362.99in)
(C)(Maximumdiggingdepth)5.66m(222.83in)6.06m(238.58in)6.49m(255.51in)
(D)(Maximumdiggingdepthovera
lengthof2.44m(96.06in))
5.43m(213.78in)5.85m(230.31in)6.29m(247.64in)
(E)(Maximumdumpheight)6.38m(251.18in)6.61m(260.24in)6.69m(263.39in)
(F)(Maximumworkingheight)9.01m(354.72in)9.24m(363.78in)9.29m(365.75in)
(G)(Minimumattachmentswing
radius)
2.98m(117.32in)2.99m(117.72in)3.05m(120.08in)
(H)(Maximumdiggingdepthona
verticalface)
4.72m(185.83in)5.08m(200.00in)5.22m(205.51in)
(I)(Maximumlengthofat-bottomed
trench)
2.44m(96.06in)2.44m(96.06in)2.44m(96.06in)
Bucketandarmtypes
●
Standardbucket
◎
Generaldigging(canbeusedwithdirtwithspecicgravityof1.8tons/m3max.)
○
Lightdigging(canbeusedwithdirtwithspecicgravityof1.6tons/m3max.)
4
Loading(canbeusedwithdirtwithspecicgravityof1.2tons/m3max.)
×
Cannotbeused(notcoveredbywarranty)
CX160C
Bucketcapacity(m3)ISO
heaped
0.550.620.70
Numberofteeth
55
Width(mm)901(828)1016(943)1091(1018)
●Speciedarm
Standardarm(2.62m
(103.15in))
◎●○
Shortarm(2.23m
(87.80in))
◎◎●
Longarm(3.05m
(120.08in))
●◎x
Theguresin()aredimensionsexcludingthesidecut-
ters.
Shoetype
CX160C
Shoewidthandname
500mmgrouser/link
500mmgrouser600mmgrouser700mmgrouser
Groundpressure
49kPa43kPa36kPa
Overalltrackwidth
2490mm2490mm2590mm2690mm
Quickcoupler(Optional)
Dimensionsneededtotthequickcoupler
Bucketpindiameter90mm(3.5in)
Widthbetweenlugs
326mm(12.8in)
Minimumdistancebetweenbucketcenters
460mm(18.1in)
Maximumdistancebetweenbucketcenters
520mm(20.5in)
NOTE:Thequickcouplerdescribedinthismanualisde-
signedtobeusedwithCASECONSTRUCTIONbuckets.
Thisbeingsaid,otherbucketsmaybeused,providedthe
diameterofthepinsandthewidthbetweenthebucket
lugsaremodiedtomeetthedimensionsneededtot
thequickcoupler(pins,washers,bushings,etc.).
ConsultyourCASECONSTRUCTIONDealer.
8-9
