Boundarywarning
The“BoundAlarmAudio”windowonthe
“PrecisionFarmingSetup”screen(Home
>Toolbox>PF)determineswhetheran
audiblealarmsoundswhenthevehicle
(withitsimplementorheader)entersthe
boundarywarningzone.
Theaudiblealarmisautomaticallyenabledandcannot
bedisabledwheneverthe“Autoguidance”applicationis
activeinthedisplay.Thewindowisdimmedandcan-
notbeselected.Theaudiblealarmbeepsslowlyfor3s,
andthenmorerapidlyfor2stoalerttheoperatorthatthe
vehicle(withitsimplementorheader)isapproachinga
eldboundary.Afterthis5speriod,asinglealarmtone
soundsonceevery30suntilthewarningconditionclears.
Thealarmisaccompaniedbyaashing“Approaching
Boundary”iconinthestatusandwarningiconarea.
Whenthe“Autoguidance”applicationisnotactive,theop-
eratorcanturntheaudiblealarmONorOFF .Ifthealarmis
turnedon,asingletonesoundsonceevery30suntilthe
warningconditionclears.IfthealarmisturnedOFF ,no
audiblealarmoccurs.The“ApproachingBoundary”icon
displaysinthestatusandwarningiconarearegardlessof
whethertheaudiblealarmisturnedONorOFF.Theicon
asheswhenthealarmisturnedONanddisplayswithout
ashingwhenthealarmisturnedOFF.
NOTE:Thealarmbehavioroccursifanypartofthevehi-
cle(withitsimplementorheader)entersthealarmzone.
RCIL11DSP265BBG29
RCIL11DSP473BBG30
Thealarmzoneisdifferentforforwardandreverseoper-
ation.
Ifthevehicleisoperatinginaforwardgear,the
approachingboundarywarningoccurs.
•
Whenthevehicleiswithin5m(16ft)oftheboundary
OR
•
Whenthevehicle,atitscurrentspeed,iswithinthe
alarmlookaheaddistanceoftheboundary,asdened
inthe“AlarmLookAhead”window(Home>Toolbox>
PF)
RCIL11DSP473BBG31
