2-ICONSANDWINDOWS
Theobjectpoolicondisplayswhilean
ISOBUSimplementortooluploadsits
componentstothedisplay.
Thedisketteicondisplayswhenthe
objectpoolfromanISOBUSimplement
issavedtoorloadedfromNon-Volatile
Memory(NVM)inthedisplay.
Thetelematicsletransferserveris
connectedbutidle.
Thedisplayisuploadingtothe
telematicsletransferserver.
Theletransferfeatureiscongured
foranRS-232portthathasconicts.
Telematicsisenabledandconnected
tothecellularnetwork.
Telematicsisenabled,butthereisno
cellularnetworkconnection.
Telematicsisenabled,butisunableto
communicatewiththemodem.This
iconaccompaniestheTL-100and
TL-101telematicsfaultcodes.See7-1.
