2-ICONSANDWINDOWS
Moststatusiconscommunicatesimplermessages:
•
Anobjectispresentormissing.
•
Afunctionisenabledordisabled.
OR
•
Atoolisraisedorlowered.
Thetablebelowlistssomeofthemorecommoniconsyou
mayencounterinthe“Framework,”“PrecisionFarming,”
“VirtualTerminal,”and“T elematics”applications.
Thetablebelowlistssomeofthemorecommoniconsyou
mayencounterinthe“Framework,”“PrecisionFarming,”
and“VirtualTerminal”applications.
Somestatusiconsareuniquetothevehicleorthevarious
farmingapplications.Refertothevehicleoperator’sman-
ualorthesoftwareoperatingguideforinformationabout
otheruniquestatusicons.
NOTE:Manystatusandwarningiconsareinteractive.
Presstheicontodisplayadditionalinformation.
RCIL11DSP265BBG5
RCIL11DSP376BBG6
TheGPSreceiverhasacquiredavalid
GPSsignal,butnotavalidDifferential
GPS(DGPS)signal,ifapplicable.
DifferentialGPS(DGPS)correction
signalisinuse.
RealTimeKinematic(RTK)correction
signalhasbeeninterrupted.xFill™is
providingcorrectionsignaltemporarily.
Alatching“FieldMark”buttonisactively
markingitsselectedcondition.
Fieldboundaryrecordingisinprogress.
Thevehicle(withitsimplementor
header)isapproachingaeldboundary
ortheendoftheswath.
Fieldobstaclerecordingisinprogress.
Thevehicle(withitsimplementor
header)isapproachingaeldobstacle.
Thedisplaydetectsthepresenceof
thememorystick.Thememorystick
mustbeinsertedbeforepoweringthe
displayforittobedetected.
Recordingtothememorystickisin
progress.
Anactivegrower,farm,eld,andtask
mustbeselectedbeforedatacanbe
recorded.
Recordingtothedisplaymemoryisin
progress.Dataisnotbeingrecordedto
thememorystick.
Theimplementisraised.Theimplementislowered.
2-21
