Case IH AFS Pro 700 - Caution icons management

2-ICONSANDWINDOWS
Thewindowcontains:
•
Thecautionicon
•
Thefaultmessage
•
Aniconfortheproblemarea
•
Afaultcodereference
•
Abriefexplanationofthecondition
•
Aninstructionthatexplainswheretondmoreinforma-
tion
Acautionmessagecanbeacknowledgedintwoways:
Pressthe“OK”buttontoclearthemessage
andleavefaultdetectionenabledforthe
specicitemthatcausedthefault.Aslong
asthefaultconditionispresent,thewarning
iconcontinuestoashinthestatusand
warningarea,andanaudiblealarmsounds
every10s.Ifthefaultconditionclears,
thecautioniconclearsandthealarmis
suppressed,butthesystemcontinuesto
monitorthespecicitem.
Pressthe“Ignore”buttontoacknowledge
themessageanddisablefaultdetection
forthespecicitemthatcausedthefault.
Thecautioniconremainsinthestatus
andwarningareaasareminderthatthe
conditionisstillpresent,buttheiconis
dimmed(ordisabled)andnolongerashes.
Theaudiblealarmisalsosuppressed.
NOTICE:DonotuseIgnoretoacknowledgeamessage
unlessthereisaknownsensorproblemforwhichrepairs
mustbedelayeduntilareplacementsensorisavailable.
Faultdetectionforthespecicitemisre-enabledatthe
nextpowercycleorbyoperatoractivationonthe"Fault
Archive"screenindiagnostics(Home>Diagnostics>
Fault).
Themessagewindowdoesnotredisplay.
Refertothe"FaultArchive"screeninDiagnosticsformore
informationontheactivefaultcode(Home>Diagnostics
>Fault).
2-20
