4-OPERATINGINSTRUCTIONS

Pattern:ISOtype

Left–handcontrollevercontrolfunction

1.Armout

2.Armin

3.Swingright

4.Swingleft

SMIL16MEX0587AB4

Right–handcontrollevercontrolfunction

5.Boomlowering

6.Boomraising

7.Bucketout

8.Bucketin

SMIL16MEX0588AB5

4-14
