9-ACCESSORIES

NOTE:Ifthemachineisalsoequippedwithrstauxiliary

hydrauliccircuit(optional),thebuttontooperatethehy-

draulicbreakerislocatedontheright-handcontrollever

undertheproportionalswitch.Tooperatethehydraulic

breakerpushtherightbuttontooperatethesingleacting

hydraulicattachment.

SMIL16MEX1265BA4

9-11
