9-ACCESSORIES

Proportionalswitchsetting:

•

Setleft-handorright-handproportionalswitchrespec-

tivelyforCloseorOpen.

NOTE:thedefaultcontrolforproportionalswitchistoleft-

handreleaseandtoright-handclamp.

SMIL17MEX2979AA10

Fluxsetting:

•

Enableuxsettingfromlevel1tolevel5.

SMIL17MEX2980AA11

Savesettingvalue:

•

Selectthesaveicontosavesettings.

SMIL17MEX2986AA12

9-15
