Case CX60C - Page 270

9-ACCESSORIES
Secondauxiliaryhydrauliccircuits(4-way-Rotating-Lowow)
Themachinecanbeprovidedwithanadditionalsecondauxiliaryhydrauliccircuit.Thistypeofcircuitcanoperatethe
attachmentsfeaturingsecondaryhydraulicactuationforpositioning,suchasrotatinggrabsortiltablebuckets.
Hydraulicconnections
Thetwofeedlinesarelocatedbothontheleft-handsideofthearmbesidetherstauxiliaryhydrauliccircuittoallow
properandsafeconnectionoftheattachmenthydrauliclinestothesecondauxiliaryhydrauliccircuit.
SMIL18MEX0079BA13
Hydraulicconnection
(B1).Counterclockwiserotation
(B2).Clockwiserotation
QuickdisconnectISO7241-A-10maleport
Operationalsettings
Theowrate/pressurecharacteristicofthesecondauxiliaryhydrauliccircuitissettingbymeanstheenginepower
applied.
Thesecondauxiliaryspecicationsforsecondauxiliarycircuitaresetfromfactory:
Maximumowrate(PTOpump)30L/min(7.9USgpm)withenginesetat2100RPM
Maximumoperatingpressure
160bar(2320psi)
9-16
