9-ACCESSORIES

Donotoperatetheaugertothesideofthemachine.The

machinemaybecomeunstableandundercarriagecom-

ponentslifemaybereduced.

SMIL16MEX1406AA42

Operatetheexcavatorcarefullytoavoidhittingtheboom

withthebit.

SMIL18MEX0595AA43

Donotoperatetheaugerwhilestriking.Thiscancause

damagetotheworkingdeviceandtotheswingsystem.

SMIL17MEX2812AA44

9-30
