9-ACCESSORIES

Advisedmodels

NOTICE:allattachmentshownonthismanualareexclusivetotheNorthAmericanMarket.Toallothermarkets

contactyourauthorizedCASECONSTRUCTIONdealer,beforepurchasinganattachment.

NOTE:contactyourauthorizedCASECONSTRUCTIONdealer,beforepurchasinganattachment.

Driveunit(1)

ModelMaximum

unitweight

Maximum

working

pressure

Maximum

workingow

X147577.1kg

(170lb)

220bar

(3190psi)

35–75L/

min(9.2

–19.8US

gpm)

SMIL17MEX2793AA45

Pendulummount(2)

ModelUnitweight

Pendulumaugermount

27.7kg(61lb)

SMIL17MEX2834AA46

Cradlemountbracket(3)

ModelUnitweight

Cradleaugermount56.2kg(124lb)

SMIL17MEX2781AA47
