9-ACCESSORIES
8.Fromtheoperator’sseatperformavisualinspection
andcheckinordertoverifythecorrectrearjawen-
gagement.
Ifthefrontlockisnotvisibleproceedasfollows:
•
Fullyextendthebucketcylinder.
•
Lowertheredcover(A)todisengagethehydraulic
quickcouplingactivationswitch(B)andmaintainitin
releasepositionfor2s.
•
Holdthebucketcurlleverforapproximatelyfor3–5s
toallowthehooktofullyretractplacecouplerinthefully
curledposition.
•
Lifttheredcover(A)toactivatethehydraulicquickcou-
plingswitch(B)toengagecouplersystemfor2s,then
lowertheredcover(A)toreleasethequickcoupling
switch(B).
•
Holdthebucketcurlleverforapproximatelyfor3–5s
toallowthejawtofullyengageandclampthebucket
pin.
•
Performanewvisualinspectionandcheckagaintover-
ifythecorrectrearjawengagement.
SMIL18MEX0596BA7
SMIL18MEX0091BA8
9-50
