9-ACCESSORIES

NOTE:Ifisnotpossibletoperformthevisualinspection

andcheckfromthecab,theoperatormustgetoutofthe

cabandstandinasafeplacetovisuallyinspectbefore

operatingthemachine.

SMIL18MEX0597AA9

9.Toensurethatthebucketpinsaresecurelyheldby

thecoupler,applypressuretothebucketbyrotating

itagainstthegroundandawayfromthemachinebe-

foreoperation.

10.Ifthebucketisnotcorrectlyattached,repeatthese-

quencefromstep1.

SMIL17MEX2828AA10

9-51
