3-CONTROLSANDINSTRUMENTS
(3)Enginecoolanttemperaturegauge
Theenginecoolanttemperaturegaugeindicatesthetem-
peratureofthecoolant.
Blackrange(A):between40–115°C(104–239°F)
Redrange(B):above115°C(239°F)
Iftheindicatorisintheredrange(B)orlight(C)turns
ONinred,stoptheengineandchecktheenginecooling
system.
Whentheredrange(B)orlight(C)turnsONinred,donot
stopabruptlytheengine,butruntheengineatmedium
speedtoallowittocoolgradually,thenstoptheengine.
NOTICE:iftheengineisstoppedwithoutcooleddown
running,thetemperatureofenginepartswillrisesud-
denly,andthiscancausesevereenginetrouble.
NOTICE:ifthegaugeindicatestheredrangeorlightturns
ONinredeventhoughthemachineisonthenormalcon-
dition,consultyourCASECONSTRUCTIONdealer.
SMIL16MEX0614AA5
(4)Hydraulicoiltemperaturegauge
Thehydraulicoiltemperaturegaugeindicatesthetemper-
atureofthehydraulicoil.
Blackrange(A):between40–105°C(104–221°F)
Redrange(B):above105°C(221°F)
Iftheindicatorisintheredrange(B)orlight(C)turnsON
inred,reducetheloadonthesystem.
Ifthegaugestaysintheredrange,stopthemachineand
checkthecauseoftheproblem.
NOTICE:ifthegaugeindicatestheredrangeorlightturns
ONinredeventhoughthemachineisonthenormalcon-
dition,consultyourCASECONSTRUCTIONdealer.
SMIL16MEX0615AA6
(5)Fuellevelgauge
Thefuelgaugeindicatestheamountoffuelinthefuel
tank.
Fillthefuelwhentheredrange(A)orlight(B)turnsON
inred.
NOTICE:ifthegaugeindicatestheredrangeorthelight
turnsONinredeventhoughthemachineisonthenormal
condition,consultyourCASECONSTRUCTIONdealer.
SMIL16MEX0616AA7
