Case CX60C - Page 84

3-CONTROLSANDINSTRUMENTS
2.WARNINGLIGHTS
SMIL16MEX0520FB8
(A)Previouspagebutton
(B)Nextpagebutton
(1)Emergencywarninglight
(2)Batterychargingwarninglight
(3)Fuellevelwarninglight
(4)Enginecoolanttemperaturewarninglight
(5)Hydraulicoiltemperaturewarninglight
(6)Engineoilpressurewarninglight
(7)Checkenginewarninglight
(8)Stopenginewarninglight
(9)Aircleanerwarninglight
(10)Overloadwarninglight
(11)DieselParticulateFilter(DPF)warninglight
(12)HighExhaustSystemTemperature(HEST)warning
light
(13)DieselParticulateFilter(DPF)regenerationacknowl-
edgewarninglight
(14)DieselParticulateFilter(DPF)regenerationinhibit
warninglight
NOTE:eachwarninglightontheleft-topoftheLCDpopsuponthecenterofLCDandthebuzzersoundswhenthe
eachwarninghappens.Thepop-upwarninglightmovestotheoriginalposition,thelightsturnON,andthebuzzer
stopswhenthebuzzerstopswitchispushedorthepop-upistouched.
NOTE:whenmorethanfourwarningiconsappearonthedisplay,youcancheckalllightsusingthepreviouspage
button(A)orthenextpagebutton(B)nearthewarninglights.
