Case CX60C - Page 85

3-CONTROLSANDINSTRUMENTS
(1)Emergencywarninglight
Thislightappearsandthebuzzersoundswhenoneof
thefollowingconditionsoccur:
•
Enginecoolantoverheating(over115°C(239°F))
•
Hydraulicoiloverheating(over105°C(221°F))
•
MachineControlUnitinputvoltageabnormal
•
Acceleratordialcircuitabnormaloropen
Thepop-upwarningiconmovestotheoriginalposition
andthebuzzerstopswhenthebuzzerstopswitchis
pushedorpop-upistouched.Thisissameasfollowing
warninglights.
WhenthislightturnsON,themachinemustbechecked
andservicedimmediately.
SMIL16MEX3094AA9
(2)Batterychargingwarninglight
ThislightturnsONwhenthebatterychargingvoltageis
low.
CheckthebatterychargingcircuitwhenthislightisON.
SMIL16MEX3094AA10
(3)Fuellevelwarninglight
ThislightturnsONandthebuzzersoundswhenthelevel
offuelisbelow10%.
FillthefuelimmediatelywhenthelightisON.
SMIL16MEX3094AA11
(4)Enginecoolanttemperaturewarninglight
Thelight(1)popsuponthecenterofLCDandthebuzzer
soundswhentheenginecoolanttemperatureisover
115°C(239°F).
Thepop-uplightmovestotheoriginalpositionandturns
ONwhenthebuzzerstopswitchispushedorpop-upis
touched.
Also,thebuzzerstopsandlight(4)staysON.
Checkthecoolingsystemwhenthelight(4)turnsON.
SMIL16MEX3094AA12
3-31
