31
The Table- Values Application
The TABLE- application is used to create tables of values.
The function terms in the Graphic editor are entered into
the Value table application
(
vice versa
)
Entries of the Function Terms
The Entry window is similar to the Graphic window, although
with different assignments of the function keys.
Under the point TYPE
([
F3
])
the function type is selected,
e.g. Equation Y=
([
F1
])
, Parametric Function Parm
([
F3
])
Range and Type of Representation
The range of the value tables and the increment is set in
SET
([
F5
])
. Confirm entries with
[
EXE
]
Represent Table Values
Represent the value table with
[
F6
]
(
TABLE
)
. View the individual
values using the cursor keys
(
^
)(
down
)
.
There is also the possibility to edit the table. Under ROW
([
F3
])
individual entries can be deleted.
Change the entries with EDIT.
Graph Representation
The points of the value tables are shown with G-CON
([
F5
])
and
with the Graph GPH-PLT
([
F6
])
Table Values
• Select the Functions type with TYPE
([
F3
])
• Range and Step size are adjusted with SET
([
F5
])
To Next Page
